Husky2150金属泵
效能卓越，物超所值
•流体压力可达120psi
•专利的空气阀，可在线维修，并无需打开内腔
•环氧涂层可抵御恶劣的工作环境
技术规格
工作流体压力................................................................120 psi (8.4 bar,0.84 MPa)
工作空气压力范围.......................................................20-120psi (1.4-8.4 bar，0.14-0.84 Mpa)
空气消耗量.............................................................175scfm (4.9 m3/min)
在70psi/60gpm情况下的空气消耗量.........................................60scfm (1.7 m3/min)
自由流量..................................................................568 l/min (34.08 m3/h)
往复速度....................................................................................145cpm
每往复流量..............................................................................1.03gal(3.90 liter)
自吸高度干抽DF3666........................................................................20 ft.(6.1 m)
根据阀座，球和隔膜的不同组合而变化
输送固体颗粒.............................................................................1/4 in.(6.3 mm)
空气进口尺寸.......................................................................................1/2 in.npt(f)
流体进出口尺寸铝，不锈钢和铸铁..........................................................2in.npt(f)
重量铝......................................................................58 lbs.(26.3 kg)
不锈钢........................................................................127 lbs.(57.6 kg)
铸铁............................................................................130 lbs.(59 kg
尺寸铝,不锈钢和铸铁..........................................................17.5 in. W x 23.0 in. H* x 12.5 in. D
(443.2 mm W x584.2 mm H x 317.5 mm D)
安装孔布局.............................................6 in. (152.4 mm)x 6 in. (152.4 mm)
隔膜泵系列
Husky205 / triton 1:1 308 /Husky716/Husky1050/Husky1590/Husky2150/
Husky3300大流量自动隔膜泵
4D 150 & 4D350隔膜泵
