代理销售固瑞克原装husky2150气动隔膜泵 GARCO气动双隔膜泵 铝合金隔膜泵
机械设备
东莞
安全提示：联系对方时请说明在 加工郎 看到，切勿提前支付任何费用，谨防诈骗。如遇虚假信息，请立即 举报
详情信息
Husky 2150 金属泵
效能zhuoyue，物超所值
• 专利的空气阀，可在线维修，并无需打开内腔
• 流体压力可达120psi
• 环氧涂层可抵御恶劣的工作环境
技术规格
Zui大工作流体压力 .............................................................................. 120 psi (8.4 bar,0.84 MPa)
工作空气压力范围 .......................................................20-120 psi (1.4-8.4 bar，0.14-0.84 Mpa)
Zui大空气消耗量 .........................................................................................175 scfm (4.9 m3/min)
在70psi/60gpm情况下的空气消耗量 ..........................................................60 scfm (1.7 m3/min)
Zui大自由流量 ............................................................................................ 568 l/min (34.08 m3/h)
每往复流量 .......................................................................................................1.03 gal(3.90 liter)
Zui大自吸高度干抽 DF3666 ....................................................................................... 20 ft.(6.1 m)
Zui大往复速度 ..................................................................................................................145 cpm
根据阀座，球和隔膜的不同组合而变化
Zui大输送固体颗粒 ............................................................................................... 1/4 in.(6.3 mm)
空气进口尺寸 ............................................................................................................. 1/2 in.npt(f)
流体进出口尺寸 铝，不锈钢和铸铁 ............................................................................2 in.npt(f)
重量 铝 ................................................................................................................. 58 lbs.(26.3 kg)
铸铁 .............................................................................................................. 130 lbs.(59 kg)
不锈钢 ....................................................................................................... 127 lbs.(57.6 kg)
尺寸 铝,不锈钢和铸铁 ..........................................................443.2 mm W x 584.2 mm H x 317.5 mm D
安装孔布局 ............................................................................. 6 in. (152.4 mm)x 6 in. (152.4 mm)
效能zhuoyue，物超所值
• 专利的空气阀，可在线维修，并无需打开内腔
• 流体压力可达120psi
• 环氧涂层可抵御恶劣的工作环境
技术规格
Zui大工作流体压力 .............................................................................. 120 psi (8.4 bar,0.84 MPa)
工作空气压力范围 .......................................................20-120 psi (1.4-8.4 bar，0.14-0.84 Mpa)
Zui大空气消耗量 .........................................................................................175 scfm (4.9 m3/min)
在70psi/60gpm情况下的空气消耗量 ..........................................................60 scfm (1.7 m3/min)
Zui大自由流量 ............................................................................................ 568 l/min (34.08 m3/h)
每往复流量 .......................................................................................................1.03 gal(3.90 liter)
Zui大自吸高度干抽 DF3666 ....................................................................................... 20 ft.(6.1 m)
Zui大往复速度 ..................................................................................................................145 cpm
根据阀座，球和隔膜的不同组合而变化
Zui大输送固体颗粒 ............................................................................................... 1/4 in.(6.3 mm)
空气进口尺寸 ............................................................................................................. 1/2 in.npt(f)
流体进出口尺寸 铝，不锈钢和铸铁 ............................................................................2 in.npt(f)
重量 铝 ................................................................................................................. 58 lbs.(26.3 kg)
铸铁 .............................................................................................................. 130 lbs.(59 kg)
不锈钢 ....................................................................................................... 127 lbs.(57.6 kg)
尺寸 铝,不锈钢和铸铁 ..........................................................443.2 mm W x 584.2 mm H x 317.5 mm D
安装孔布局 ............................................................................. 6 in. (152.4 mm)x 6 in. (152.4 mm)
