单向轴承-超越离合器-AS,ASNU
机械设备
武进
安全提示：联系对方时请说明在 加工郎 看到，切勿提前支付任何费用，谨防诈骗。如遇虚假信息，请立即 举报
详情信息
是否进口
非进口
品牌
Tiger
型号
AS30
用途
印刷机械
内径
30（mm）
外径
62（mm）
厚度
16（mm）
重量
0.22（kg）
体积规格
小型 28≤D≤55
保持架及其材料
F1碳钢
滚动体类型
球面滚子
滚动体列数
单列
滚道类型
深沟滚道
使用特性
高温
载荷方向
二者皆可
类型
多款供选
是否含油
含油
type as is a roller type freewheel non bearing supported.
bearings are required to support axial and radial loads.
lubrication and sealing must also be provided by the
installation.
nominal outside dimensions are the same as series 62.. ball
bearings.
a typical arrangement is to install this type alongside a series
62 bearing.
the inner race is keyed to the shaft (except 6 mm bore).
the outer race has a positive r6 tolerance to give a press fit
in a h7 housing.
the outer housing must be strong enough to not expand after
assembly.
this design can accept an axial mis-alignment of inner and outer
race of ± s/2.
非进口
品牌
Tiger
型号
AS30
用途
印刷机械
内径
30（mm）
外径
62（mm）
厚度
16（mm）
重量
0.22（kg）
体积规格
小型 28≤D≤55
保持架及其材料
F1碳钢
滚动体类型
球面滚子
滚动体列数
单列
滚道类型
深沟滚道
使用特性
高温
载荷方向
二者皆可
类型
多款供选
是否含油
含油
type as is a roller type freewheel non bearing supported.
bearings are required to support axial and radial loads.
lubrication and sealing must also be provided by the
installation.
nominal outside dimensions are the same as series 62.. ball
bearings.
a typical arrangement is to install this type alongside a series
62 bearing.
the inner race is keyed to the shaft (except 6 mm bore).
the outer race has a positive r6 tolerance to give a press fit
in a h7 housing.
the outer housing must be strong enough to not expand after
assembly.
this design can accept an axial mis-alignment of inner and outer
race of ± s/2.
