详情信息
产品名称: cba8060系列防爆防腐主令控制器（ⅱc）适用范围application区、2区危场所.iia、iib、iic类爆炸性气体环境can be used zone 1 and zone 2 dangerous places.can be used in iia,iib,iic group explosive atmosphere.
型号含义model implication总单元型号含义application of chief part
主要技术参数 main technical parameters
使用类别using sorts额定工作电压（v）ratedvoltage额定工作电流（a）ratedcurrent 防护等级protectioncategory 防爆标志ex-mark 防腐等级corrosion-proof category 进线口螺纹（g")inlet’s thread 电缆外径（φ,mm）cable’soutside diameterac-3 ac-4 220 380 10 ip65 exed ii ct6 wf2 3/4* 8-14
*注：本产品通头正常配置为g3/4“，如用户要求通头配置为g1/2"请注明。通头为普通型通头，如用户要求采用复合密封则请注明。*note:operating post normal installing has one out let teminalwhose diameter is g3/4",pleasenoted if you require g1".
产品特点 features增安型外壳，内装元件为防爆元件。外壳采用玻璃纤维增强不饱和聚酯树脂压制而成，具有外形美观，耐腐蚀，抗静电，耐冲击及热稳定性好等优良性能。隔爆型控制开关具有结构紧凑，可靠性好，体积小,通断能力强，寿命长并有多种功能供用户选配。防爆按钮采用超声波封装工艺，保证了可靠的结合强度，按钮的功能可以两单元自由给合，防爆指示灯采用特殊设计，交流220-380v通用。外露紧固件均采用不锈钢，为防掉式设计维修方便.壳体和盖的接合面采用迷宫式结构，具有较好的防水，防尘能力。符合gb3836-2000,iec60079标准要求。safety reinforced shell,inside are mounted explosion-separate typeelementsthe shell mould-shaped by glass fiber reinforced and unsaturatedploysterelegant-insisting impact-withstanding and perfactions ofcorrosion-proofing,electro static-insisting impact-withst and ding and perfact thermalreliability.etcthe explosion-separate type,control switchwith compactstructure,steady property,small volume,high capacity,and long-trmlife hasseveralfunctions to e selected freely.explosion-proofing button byultrasonicencapsulation arts,ensuring the dependable combining intension thefunctionof it can combine freely in two units.the explosion-proof indicatorby specialdesign,using within the ac voltage soope of 220v-380vgenerally.all the exposed fastening pieces are made of stainless steelandof anti-lost type,which be convenient to maintaining.the joint of shell and cover is the form of deviou-labyringhiantruture,water-proof,dust-proof.suitable for gb3836-2000,iec60079 standard request.
外形示意图 main technical parameters一单元壳体外形及安装尺寸outluneand installing size offirst unithullcba8060-a1二单元壳体外形及安装尺寸outline and installing size of second unithullcba8060-a2三单元壳体外形及安装尺寸outline and install ing sizeof thirdunit hullcba8060-a3
本产品的加工定制是是，品牌是旭升电器，型号是CBA8060，额定电压是200（V），额定电流是10（A），用途是控制按钮，产品认证是2
